2 cm / 0.79 in Slide-On Zamak Palaska Buckle – Custom Production SB 25690

2 cm / 20 mm Slide-On Zamak Palaska Buckle

This slide-on zamak palaska buckle is a metal fastening component for 2 cm / 20 mm webbing, straps and belt-style connections. It can be used in bags, belts, workwear, accessories, pet-collar style products and textile strap systems where a compact metal buckle is required.

The buckle is not a certified safety component by default. For load-bearing, pet-collar or outdoor applications, the final product must be tested with the real strap, stitching, rivets and expected load.

20 mm Strap Compatibility

This buckle is designed for 20 mm / 0.79 in strap width. A narrower strap may move inside the buckle, while a thicker or stiffer strap may not pass smoothly through the slide-on structure.

Before production, evaluate strap width, thickness, stiffness, coating, edge finish and the way the strap is fixed to the product.

Dimensions and Material

• Strap width: 2 cm / 20 mm / 0.79 in
• Outer length: 49.3 mm / 1.94 in
• Outer width: 24.5 mm / 0.96 in
• Material: Zamak zinc alloy
• Attachment type: Slide-on palaska buckle

Plating Options

The product page lists nickel, black nickel and gold plating options. Choose the plating together with the other metal trims on the product, such as rivets, hooks, strap adjusters, D rings and zipper pullers.

For custom plating, different finishes or special production requirements, quantity, lead time and plating cost should be confirmed before ordering.

Typical Applications

• Small bags, shoulder straps and accessory straps
• 20 mm belts, webbing and leather straps
• Workwear, uniforms and utility textile details
• Pet-collar style applications after strength testing
• Leather goods, faux leather accessories and promotional products
• Sample making, repair work and small-batch production

Selection Checklist

• Use 20 mm / 0.79 in strap width.
• Check strap thickness and slide-through comfort.
• Match the plating with the other hardware on the product.
• Test under the real load and use conditions.
• Check stitching, rivets or strap-end fixing together with the buckle.

Related Categories

For similar hardware, review the Bag Buckles, Rings and Hooks category and the Slide Buckles and Strap Hardware product listings.

Frequently Asked Questions

What strap width does this buckle fit?

It is designed for 2 cm / 20 mm / 0.79 in webbing, straps and belts.

What are the outer dimensions?

The outer length is 49.3 mm / 1.94 in and the outer width is 24.5 mm / 0.96 in.

What material is used?

The buckle is made from zamak zinc alloy.

Which finishes are available?

The product page lists nickel, black nickel and gold plating options.

Can it be used for bags and belts?

Yes, when the strap width, thickness and expected use are suitable for the buckle.

Can it be used for pet collars?

It may be used in pet-collar style products after testing the final collar, stitching, strap and expected pulling load.

Is it the same as a plastic side-release buckle?

No. This is a zamak metal slide-on buckle. It does not have the same plastic side-release locking mechanism.
